Koroseal / Type II wallcovering
Arco
8 colorways · Vinyl
- Type II
- Class A, ASTM E-84
- NFPA 286
- 52-54 in wide
- Non-Woven backing
From $42.44 per yard · 15 yd minimum
Arco is a Type II vinyl wallcovering by Koroseal. It comes on non-woven backing, 52-54 in wide. Installation: non-reverse hang, straight match.
Arco colorways
HanaRA21-06
ÉtretatRA21-01
WalesRA21-02
MaltaRA21-03
RomeRA21-04
SydneyRA21-05
MoabRA21-07
CaboRA21-08
Specifications
- Collection
- Commercial Wallcoverings
- Material
- Vinyl
- Backing
- Non-Woven
- Product type
- Wallcovering
- Roll width
- 52-54 in (132-137 cm)
- Pattern match
- Non-Reverse Hang, Straight Match
- Fire rating
- Class A, ASTM E-84
- Vertical repeat
- 24 in (61 cm)
- Horizontal repeat
- 52 in (132 cm)
- Total weight
- 20 oz. ply (618 g. plm.)
- Weight per area
- 13.3 oz. psy (451 g psm.)
- Nominal pattern width
- 51 in.
- Tensile (minimum)
- 50 x 55 lbf (222 x 245 N)
- Tear (minimum)
- 25 x 25 lbf (111 x 111 N)
- WA spec
- WA-101, Type II
- Federal spec
- CCC-W-408D, Type II
- ASTM F-793
- Category V, Type II
Source: Koroseal product pages and Arco Fact Sheet. Only values identical for all 8 colorways are shown here.
Fire and code compliance
| Test or standard | Result | Test condition |
|---|---|---|
| NFPA 255 (ASTM E-84, CAN S102M) Tunnel Test | Class A Rating | When applied to GRC board with A-848-B adhesive |
| NFPA 286 Corner Burn Test | Meets requirements for Flame Spread, Smoke Developed, and Flashover | When applied to 5/8" Type X Gypsum board with A-848-B adhesive |
| CE certification | EU classification in accordance with EN 15102:2007 + A1:2011 | As stated on the fact sheet |
| Indoor air quality | California 01350 - Meets emission requirements for schools and offices | As stated on the fact sheet |
Results apply under the stated test conditions. Confirm requirements with your project's authority having jurisdiction. How to read fire test data.
Documents and downloads
Product data
Installation and care
Sustainability
Questions about Arco
- Is Arco a Type II wallcovering?
- Yes. Koroseal documents Arco as a Type II commercial wallcovering; see the fact sheet below for the specification references.
- What is the fire rating of Arco?
- NFPA 255 (ASTM E-84, CAN S102M) Tunnel Test: Class A Rating (When applied to GRC board with A-848-B adhesive). Confirm requirements with your authority having jurisdiction.
- How many colorways does Arco have?
- 8: Hana, Étretat, Wales, Malta, Rome, Sydney, Moab, Cabo.
- How is Arco priced and ordered?
- By the yard: from $42.44 per yard, 15 yard minimum in increments of 15 yards; orders under 30 yards include a $3.50 per yard cut fee. Each colorway page shows its exact price.
Project pricing
Request a quote for Arco
Tell us the colorways and quantities. To quote several colorways or patterns together, add them to your project list.
